Product Details:
Place of Origin: CHINA
Brand Name: HaiQun
Certification: SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Model Number: ASME / ANSI B16.9 UNS S31803 / 2205
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden box and iron shelf or as percustomers requirement
Delivery Time: 30-60 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000

Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads

Description
Standard: SCH.10, SCH.10S, SCH.20, SCH.30, SCH.40, SCH.40S, STD Shape: Equal
Outer Diameter: 6mm - 200mm Reduction Ratio: About 10%
General: Semi Elliptical Head Material: SA516
Surface: Coating
High Light:

Industry ASME Tank Heads

,

ASME Tank Heads

,

ASME Tank Head Dimensions

Sa516 Gr70 100mm Hemispherical Tank Heads ASME Stainless Steel Dished




PRODUCT DETELS


SA516 Gr70 100mm hemispherical tank heads with ASME stainless steel dished design are specifically designed for pressure vessel applications.

  1. SA516 Gr70: SA516 Gr70 refers to a specific grade of carbon steel plate that meets the requirements of the ASME SA516 standard. Gr70 is a commonly used grade known for its excellent tensile strength, high-temperature resistance, and suitability for pressure vessel applications.

  2. 100mm: The value of 100mm represents the thickness of the tank head. This thickness is an important factor in ensuring the structural integrity and pressure-bearing capacity of the tank head for the given diameter and material.

  3. Hemispherical Tank Heads: Hemispherical tank heads are curved or domed end caps used to seal the ends of tanks or pressure vessels. Hemispherical heads offer excellent stress distribution characteristics, making them suitable for high-pressure applications.

  4. ASME Stainless Steel Dished: The term "ASME stainless steel dished" indicates that the tank heads are designed and manufactured in accordance with ASME standards. This ensures compliance with specific design requirements, material specifications, and quality control measures set forth by the American Society of Mechanical Engineers (ASME).

When utilizing SA516 Gr70 100mm hemispherical tank heads with ASME stainless steel dished design for pressure vessels, it is essential to consider factors such as material compatibility, pressure ratings, dimensional accuracy, and compliance with relevant codes and standards, including ASME Boiler and Pressure Vessel Code. Consulting with engineers, pressure vessel specialists, or manufacturers experienced in tank head design and fabrication can help ensure the proper selection, design, and manufacturing of the tank heads for your specific pressure vessel requirements.



Order information:

  1. Pls provide us with below information
  2. Material grade. Including special requirement if have
  3. Head Diameter
  4. Nom THK or min thick
  5. Straight Flange if have
  6. others special forming process

The scope of products



Applicable to various building decoration industries
Widely used in electric power, metallurgy, food, pharmaceutical, petrochemical, water treatment equipment and light industry equipment. The company can also undertake the processing of incoming drawings and samples according to customer requirements, and customize products of different specifications.



production workshop



Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads 0



equipment Exhibition

Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads 1Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads 2



A corner of the warehouse

Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads 3Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads 4



One-stop ordering of head products



Non-standard customization       In stock for two days      Customized for seven days

Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads 5



SPECIFICATIONS


Brand Name: HaiQun
Diameter: 89mm--10000mm
Thickness: 2mm--300mm
Reduction Ratio: about 10%
Material: Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method: Hot forming,cold forming
Surface Treatment: Sand Blasting,Pickling,oil,discaling
Inspection: UT,RT,MT,PT,TOFD.
Applicable Standard: ASME ,PED and GB
Certificate: ISO9001,ISO45001,OHSAS18001
Applications:

Such as oil, chemical industry, water conservancy, electric power,
boiler, machinery, metallurgy, sanitary construction etc.

Package: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product: Available



Material Carbon Steel; Stainless Steel; Special Steel
Size 50-10000mm
Thickness 2mm--300mm
Surface Treatment 1. Intermediate & Final stage Heat Treatments;
2. Sand / Shot Blasting after Heat Treatment;
3. Weld Edge Preparation (Manual & Machined)
Reduction ratio About 10%
Certificate ISO9001
Technology 1. Cold & Hot forming;
2. Hot Pressed Hemispheres and Cold Formed Segmental Hemispheres;
Applicable standard ANSI, ASME, MSS, API, DIN, JIS, BS. AWWA
Test 1. Liquid Penetrant Examination;
2. Ultrasonic Testing;
3. 100% Radiography Testing of weld seams;
4. Magnet Particle Examination;
5. Inspection under various Third party Inspection Agencies
6. NDT( after forming): DPT, RT, MPI, UT;
7. NDT: 100% DPT, UT & RT OF weld joint
Connection Welding
Application Pressure vessel



PRODUCTS


Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads 6



Product shipping packaging



Industry ASME Tank Heads Dimensions SA516 Gr70 Hemispherical Heads 7
